Innovations revolutionizing sheet metal manufacturing

By Staffan Åkervall, CIDAN Machinery Group.

Learn about the cutting-edge features that are transforming the sheet metal industry.

CIDAN Machinery Group’s Thalmann TD double folder is the future of metal processing. As the patent is pending, get to know this game changing machine. This machine utilizes cutting-edge technology to make the metal roof fabrication process smoother than ever. It is designed to enhance efficiency and take safety to new levels. By facilitating faster loading, more precision, increased capacity and more, the Thalmann TD double folder series elevates your operations.

Game-changer

Are you ready for a revolution? Meet the multihead side loader TD, a smart solution for your sheet metal processing operations. Key highlights include:

• Faster loading: Bid farewell to time-consuming loading processes – the multihead side loader TD can load up to four strips simultaneously in one swift motion when operating in four section mode. This means reduced loading times and significantly increased productivity. It’s more than 40% faster!
• Patent pending technology: Our smart system is underlining our pioneering spirit in the field of sheet metal processing. With Thalmann TD, you always have access to the latest advancements.
• Precision and flexibility: Each row of the multihead side loader TD is equipped with a vacuum injector and an ultrasonic sensor for precise height measurement of your stock. Our user-friendly software lets you choose whether to load one or more blanks, guiding you to optimal positioning.
• Versatile loading: Whether you’re handling small stripes as narrow as 3.54” or larger widths, our multihead side loader TD handles it all with ease, especially in section mode.
• Increased loading capacity: Experience less wear and tear and significantly more loading capacity compared to standard vacuum heads. With 16 suction cups delivering a 30% boost in suction force, you can confidently handle materials up to 14ga thick.

CIDAN Machinery Group is committed to pushing the boundaries of innovation, and the multihead side loader TD is a step in this direction.

Additional new innovations

In addition to the multihead side loader TD, CIDAN Machinery Group is introducing three other smart and fast features for the Thalmann TD Double folder.

1 – Fast loading with automation and efficiency

Say goodbye to manual interventions with our fast loader function. This smart solution automates back gauge positioning, eliminates the need for gripper offset and allows seamless loading of small 2.95” strips in automatic mode. Enhance gauge speed after part flipping, enabling fully automatic mode for profile creation.

2 – Vacuum gripping for precision and safety

Conquer complex scenarios with ease using the vacuum gripper. Achieve precise positioning in fully automatic mode, especially when dealing with flanges over 1.50” in height. This solution not only speeds up your processes but also enhances operator safety by eliminating manual handling.

3 – Best in class in safety

Safety is paramount, and we’ve raised the bar with our Thalmann TD double folder. It now boasts best-in-class safety features, including three strategically placed scanners that cover the entire floor area (frontside, left and right sides). These scanners activate within 1250 mm (4 feet) from the bending line, ensuring the safety of operators. An additional top-mounted scanner halts the machine when someone enters the safety area from the frontside. This intuitive and state-of-the-art safety system eliminates the need for a two-operator mode in automatic mode, enabling fast and safe panel production without factory safety pillars.

Original article source: CIDAN Machinery Group
